4-Channel | 4K 60Hz

4K 2x2 Video Wall Controller

Distributes one HDMI or DVI device (computer, laptop, DVD player, console etc.) on maximum 4 screens simultaneously.

8 Display Modes - 2x2, 1x2, 1x3, 1x4, 2x1, 3x1, 4x1 provide extra diversities on the display options. Transmit HDMI signal for up to 100 feet without losing picture quality.

Cascading Mode - 2x4, 2x8 with additional units.

Plug & Play. No driver needed.

Specifications

HDMI version
HDMI 2.0

HDCP version
HDCP 2.2

Support Input Video Resolutions

• 4K@60Hz
• 4K@25/30Hz
• 1080p@25/30/50/60Hz
• 1080i @ 50/60Hz (For Direct TV and other broadcast satellites)
• YUV4:2:2 24bit, YUV4:4:4 24bit,YUV4:2:0 24bit, RGB4:4:4 24bit

Support Output Video Resolution

• 4K@60Hz
• 1080p@60Hz (in each display)
• RGB4:4:4 24bit

Support Audio Format

• PCM 2.0
• Does Not Support Dolby Digital and DTS

Power Adapter

• Input: AC (50HZ, 60HZ) 100V-240V;
• Output: DC 12V 3A

Package

• 4 Channel 4K Video Wall Controller
• Remote Control
• 12V AC Adapter
• User Manual
